Modul Input Pulsa Yokogawa AAP135-S00 (Saluran Terisolasi)

SKU AAP135-S00

  • Part Number:

    AAP135-S00

  • Manufacturer:

    Yokogawa

  • Condition:

    Brand New & in Stock

  • Product Type:

    Modul Input Pulsa

  • Origin:

    Japan

  • Shipping Detail:

    Fedex and UPS etc

  • Warranty:

    12 months

Sering-seringlah bertanya Bersama

100% Genuine Stock, 24/7 Service

Inquiry

Modul Input Pulsa (Saluran Terisolasi)

  • Model: AAP135
  • Jumlah Saluran Masukan: 8, saluran terisolasi
  • Sinyal Masukan:
    • Tipe 2 kabel: Kontak ON/OFF, pulsa tegangan, pulsa arus (mungkin untuk memasok catu daya pemancar)
    • Tipe 3 kabel: Pulsa tegangan tipe catu daya
  • Frekuensi Input: 0 hingga 10 kHz
  • Menahan Tegangan:
    • Antara input dan sistem: 500 V AC, selama 1 menit
    • Antar saluran : 500 V AC, selama 1 menit
  • Lebar Pulsa Input Minimum: 40 µs
  • Tingkat Sinyal Masukan:
    • Input kontak: Tingkat buka/tutup kontak relai dan kontak transistor
      • Buka: 100 kΩ atau lebih besar, Tutup: 200 Ω atau kurang
    • Kapasitas kontak:
      • Saat mensuplai 12 V DC: 15 V DC 15 mA atau lebih tinggi
      • Saat mensuplai 24 V DC: 30 V DC 30 mA atau lebih tinggi
    • Input pulsa tegangan/arus (Input arus diubah menjadi tegangan.):
      • VH (tingkat tinggi): 3 hingga 24 V DC
      • VL (tingkat rendah): -1 hingga 8 V DC
      • VH-VL (nilai ayunan): 3 V atau lebih tinggi
    • Resistansi sumber sinyal: 1 kΩ atau kurang
  • Resistensi Shunt: Dapat dipilih dari tidak ada/200/500/1000 Ω. (Buka saat daya MATI dan untuk sisi siaga dalam konfigurasi dual-redundan)
  • Resistensi Pull-up: 68 kΩ (12 V DC atau 24 V DC)
  • Filter: Filter untuk menghilangkan obrolan dapat disetel.
  • Periode Pembaruan Data: 2 ms
  • Catu Daya Pemancar: Dapat memilih 24 V DC/12 V DC.
  • Nilai Pembatas: 12 V DC ±10 %: 40 mA, 24 V DC ±10 %: 30 mA
  • Konsumsi Arus Maksimum: 300 mA (5 V DC), 400 mA (24 V DC)
  • Berat: 0,3 kg
  • Koneksi Eksternal: Terminal penjepit tekanan, kabel KS, kabel konektor MIL
