1SAP260300R0001 | ABB CD522 S500 Function Module

General Information

• Extended Product Type: CD522
• Product ID: 1SAP260300R0001
• ABB Type Designation: CD522
• EAN: 4016779671668
• Catalog Description: Function module. 2 encoder inputs. 2 PWM outputs. 2 DI 24VDC. 8 configurable DI/DO 24VDC (CD522)
• Long Description: CD522: S500 Function module. 2 encoder inputs. 2 PWM outputs. 2 DI 24VDC. 8 configurable DI/DO 24VDC.

Ordering

• CN8: 85389091
• Invoice Description: Function module. 2 encoder inputs. 2 PWM outputs. 2 DI 24VDC. 8 configurable DI/DO 24VDC (CD522)
• Made To Order: No
• Minimum Order Quantity: 1 piece
• Order Multiple: 1 piece
• Selling Unit of Measure: piece

Dimensions

• Product Net Weight: 0.124 kg
• Product Net Depth / Length: 62 mm
• Product Net Height: 76 mm
• Product Net Width: 67.5 mm
• Gross Weight: 0.151 kg
• Package Level 1 Depth / Length: 84 mm
• Package Level 1 Height: 72 mm
• Package Level 1 Width: 71 mm
• Package Level 1 Units: 1 carton

Technical

• Function: 2 encoder inputs. 2 PWM outputs. 2 DI 24VDC. 8 configurable DI/DO 24VDC
• Number of Digital Configurable I/Os: 8
• Output Voltage (Uout): 24 V DC
• Output Current: 2 A
• Degree of Protection: IP20
• Supply Voltage: 24 V DC
• Ambient Air Temperature: Operation 0 ... +60 °C, Storage -40 ... +70 °C

Additional Information

• Product Main Type: CD522
• Product Name: Distributed Automation I/Os

Classifications

• eClass: 27-24-22-05
• ETIM 8: EC001422 - PLC function/technology module
• UNSPSC: 32151705

Environmental

• SCIP: 2084bd69-e6ed-40c9-ac25-8cac44e581ca Germany (DE)
• WEEE B2C / B2B: Business To Business
• WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)

Where Used (as part of "kit")

• 1 Products
  • Identifier: 1SAP182500R0001
  • Description: TA513-ADV:AC500,Advanced democase ETHCPU
  • Type: Kit

Classifications

• Products: PLC Automation, Programmable Logic Controllers PLCs, AC500, S500 I/O modules
