ABB CI854AK01 3BSE030220R1 PROFIBUS-DP/V1 Interface Module

Features and Benefits:

• Used for connecting remote I/O and fieldbus instruments via PROFIBUS DP.
• Possible to connect PROFIBUS PA to the CI854A/CI854B via the PROFIBUS linking device LD 800P.
• The CI854A and newer CI854B can be set redundant.

General Info:

• Protocol: PROFIBUS DP-V1
• Article number: 3BSE030220R1 (CI854AK01)
• Life cycle status: Classic
• Master or slave: Master
• Number of channels: 2
• Transmission speed: 9.6 - 12,000 kbit/s
• Line redundancy: Yes
• Module redundancy: Yes
• Hot Swap: Yes
• Used together with HI Controller: Yes

Detailed Data:

• Max units on CEX bus: 12
• Connector: DB female (9-pin)
• 24V consumption: typ. 190mA

Environmental and Certification:

• Operating Temperature: +5 to +55 °C (+41 to +131 °F)
• Storage Temperature: -40 to +70 °C (-40 to +158 °F)
• Relative Humidity: 5 to 95%, non-condensing
• Protection Class: IP20 according to EN60529, IEC 529
• CE-marking: Yes
• Marine Certificates: BV, DNV-GL, LR, RS, CCS
• RoHS Compliance: -
• WEEE Compliance: DIRECTIVE/2012/19/EU

Dimensions:

• Height: 185 mm (7.3 in.)
• Width: 59 mm (2.3 in.)
• Depth: 127.5 mm (5.0 in.)
• Weight (including base): 700 g (1.5 lbs)
