Foxboro FBM217 P0916PW Discrete Input Interface Module

Description

The FBM217 module provides 32 discrete input channels, each capable of accepting a 2-wire input from a DC voltage source. It is designed to interface electrical input signals from field sensors to the module's Fieldbus.

Specifications

• Input Channels: 32 isolated channels.

• Input Voltage Range:

  • 15 to 60 V DC

  • 120 V AC/125 V DC

  • 240 V AC

• Input Current: 2.2 mA (typical) at 30 V DC.

• Power Consumption: 3 W (maximum) at 24 V DC.

• Communication: Redundant 2 Mbps Fieldbus communication.

• Dimensions: Approximately 10.2 cm x 11.4 cm x 4.5 cm.

• Environment: Compact and rugged design suitable for Class G3 (harsh) environments.

Features

• Supports single or redundant configurations for enhanced reliability.

• Executes programs for Discrete Input, Ladder Logic, Pulse Count, and Sequence of Events.

• Includes various Termination Assemblies (TAs) with:

  • High voltage attenuation.

  • Optical isolation for inputs.

  • External power connection for device excitation.

• Designed for compatibility with Foxboro DCS systems.
