GE Fanuc Series 90-70 IC697BEM713 Bus Transmitter Module

Key Features:

High-Performance Parallel Programmer Interface:

• Provides a high-speed connection for programming, ensuring efficient and quick data transfer to and from the PLC.
• Effective data rate of 500 Kbytes/sec, allowing rapid program storage and retrieval.

Bus Expansion Interface:

• Allows the PLC to interface with additional expansion racks, significantly increasing the system's capacity and versatility.
• Supports up to 7 expansion racks, enabling extensive system scalability.

Status Indicators:

• Three LED Indicators: Provide clear and immediate status updates for:
  • Module status
  • Programmer port status
  • Expansion port status

User-Friendly Configuration:

• No DIP Switches: Configuration is done via software, making it straightforward to set up and integrate the module into the PLC system.
• Simplifies the installation process and reduces the potential for errors.

Specifications:

Power Requirements:

• Current Required from 5V Bus: 1.4 Amps

Programmer Interface Specification:

• Effective Data Rate: 500 Kbytes/sec
• Time to Store a 16 Kbyte Program: 20 - 30 seconds
• Maximum Cable Length: 50 feet (15 meters)

Expansion Interface Specification:

• Maximum Cable Length: 50 feet (15 meters) per system
• Effective Data Rate: 500 Kbytes/sec
• Electrical Isolation: Non-isolated differential communications
