GE | PCIE-5565 | Reflective Memory Node Card

GE PCIE-5565PIORC Reflective Memory Node Card

The GE PCIE-5565PIORC is a low profile PCI Express (PCIe) Reflective Memory node card. It provides a high-speed, low latency, deterministic interface for data sharing between up to 256 independent systems (nodes) at rates up to 170 Mbyte/s.

Key Features

• Form Factor: Low profile PCIe.
• Memory Options: Configurable with 128 MB or 256 MB of onboard SDRAM.
• Network Transfer Rate: 43 Mbyte/s (4 byte packets) to 170 Mbyte/s (64 byte packets).
• Dynamic Packet Size: 4 to 64 bytes of data.
• Fiber Connection:
  • Multimode fiber: Up to 300m.
  • Single mode fiber: Up to 10km.
• Node Support: Up to 256 nodes.
• Data Consistency: Data written to memory in one node is also written to memory in all nodes on the network.
• High-Speed Network: 2.12 Gbaud serially.
• No Processor Overhead: Transparent data transfer, no I/O overhead required.
• FIFO Buffers: Transmit and Receive FIFOs buffer data during peak data rates to optimize performance.
• Redundant Transfer Mode: Provides extra error suppression.
• Error Detection: Robust error management.
• Interrupt Generation: Any node on the network can generate an interrupt in any other node or all nodes with a single command.
• DMA Channel: One independent DMA channel.
• PCI Express Signaling: 2.5GHz.
• RoHS Compliance: Yes.
• Firmware: Upgradable in the field.
