General Electric DS215TCQAG1BZZ01A Analog I/O Board

Description

This DS215TCQAG1BZZ01A board is a critical component within the Mark V system, responsible for conditioning and scaling a variety of analog signals. It ensures accurate data acquisition and processing, making it essential for industrial automation and control applications.

Specifications

• Signal Type: Voltage, current, and temperature signals

• Input Range: ±10 V, ±5 V, ±2 V, ±1 V, 0 to 5 V, 0 to 10 V

• Input Resolution: 16 bits

• Accuracy: ±0.1% of full scale

• Conversion Time: 2 μs

• Input Impedance: 100 MΩ

• Common Mode Rejection Ratio (CMRR): 80 dB at 50 Hz

• Normal Mode Rejection Ratio (NMRR): 60 dB at 50 Hz

• Operating Temperature: -40°C to +70°C

• Storage Temperature: -55°C to +85°C

• Dimensions: 115 x 75 x 23 mm (4.5 x 2.9 x 0.9 in)

• Weight: 0.3 kg (0.2 lb)

Features

• Analog Signal Conditioning: Effectively conditions and scales diverse analog signals.

• Enhanced Signal Integrity: Advanced techniques minimize noise and ensure reliable operation.

• Versatile Compatibility: Handles a wide range of signal types, including voltage, current, and temperature.

• Robust Construction: Built to withstand demanding industrial environments.

• Ease of Integration: Seamlessly integrates into the Mark V control system.
