ProSoft MVI69E-MBS Modbus Serial Enhanced Communication Module

SKU MVI69E-MBS

  • Part Number:

    MVI69E-MBS

  • Manufacturer:

    Prosoft

  • Condition:

    Brand New & in Stock

  • Product Type:

    Enhanced Communication Module

  • Origin:

    Germany

  • Shipping Detail:

    Fedex and UPS etc

  • Warranty:

    12 months

Frequently inquire Together

100% Genuine Stock, 24/7 Service

Inquiry

Description

The MVI69E-MBS module provides Modbus Serial connectivity, enabling communication between CompactLogix™ processors and various Modbus devices. It includes an Add-On Profile and Add-On Instruction to simplify commissioning and integration into the CompactLogix system.

Specifications

  • Ports: Two serial ports, each configurable as Master or Slave
  • Communication Parameters:
    • Baud Rate: 110 to 115K baud
    • Stop Bits: 1 or 2
    • Data Size: 7 or 8 bits
    • Parity: None, Even, Odd
  • Modbus Modes:
    • RTU mode (binary) with CRC-16
    • ASCII mode with LRC error checking
  • Command List:
    • Up to 250 commands per Master port
    • Fully configurable for function, slave address, register addressing, and word/bit count
  • Power Supply: 500 mA max @ 5V DC

Features

  • Add-On Instruction:Creates UDTs (User-Defined Types) for logical definitions of I/O, status, and control data
  • Diagnostic Data:Accessible in processor controller tags for monitoring node health
  • Module Configuration:Configuration stored in the CompactLogix project (ACD file)
  • Floating Point Data:Supports Enron and Daniel-style floating point implementations
  • SCADA and Field Device Interface:Ideal for SCADA and field device interface applications
  • Polling:Configurable polling of command list (continuous or on change of state)
  • Error Codes:Provided on a per-command basis for easier troubleshooting
