Rockwell ProSoft PLX31-EIP-MBS4 EtherNet/IP Modbus Serial 4 Port Communication Gateway

The detailed specifications for the provided device:

• Power Supply:

  • Nominal: 24 VDC
  • Allowed Range: 10 to 36 VDC
  • Terminals: Positive, Negative, GND
  • Current Load:
    • Nominal @ 24 VDC: 300 mA
    • Maximum @ 10 to 36 VDC: 610 mA

• Operating Conditions:

  • Temperature: -25°C to 70°C (-13°F to 158°F)
  • Storage Temperature: -40°C to 80°C (-40°F to 176°F)
  • Shock: IEC 60068-2-27; 15G @ 11ms, 3-Axis (Operational), 30G @ 18ms, 3-Axis (Non-Operational)
  • Vibration: IEC 60068-2-6; 5G @ 10 to 150 Hz
  • Relative Humidity: 5% to 95% RH with no condensation

• Dimensions:

  • Height x Width x Depth: 5.38 x 1.99 x 4.38 in (13.67 x 5.05 x 11.13 cm)

• LED Indicators:

  • Configuration (CFG), Error (ERR), Power (PWR), Hardware Fault (FLT), Network Status (NS), EtherNet/IP™ Class I or Class III Connection Status (EtherNet/IP Only), Module Status (MS), Module Configuration Status (EtherNet/IP Only)

• Ethernet Communication Port:

  • Link/Activity, and 100 Mbit
  • RJ45 Connector
  • 10/100Mbit full- and half-duplex

• Electrical Isolation:

  • 1500 Vrms at 50 to 60 Hz for 60 seconds, applied as specified in section 5.3.2 of IEC 60950: 1991
  • Ethernet Broadcast Storm Resiliency: less than or equal to 5000 [ARP] frames-per-second and less than or equal to 5 minutes duration

• Serial Communication Port:

  • Number of Serial Ports: 4
  • Serial Port Isolation: 2500 Vrms port signal isolation per UL 1577. Serial port communication signal uses RF (Radio Frequency) modulation signal as isolation media.

• Shipped With Each Unit:

  • 2.5 mm screwdriver
  • J180 Power Connector
  • (4) RJ45-DB9M Serial Adapter Cable (CABLE14)
  • (4) DB9 to Screw Terminal Adapter (1454-9F)

• Enclosure Rating:

  • IP20, NEMA/UL Open Type, DIN Rail
