Schneider 171CCC96020 M1/M1E Processor Adaptor

Description

• Product Name: M1/M1E Processor Adapter

• Range of Product: Modicon Momentum Automation Platform


• Product Type: Processor Adapter

Compatibility

• Software:

• Concept Version V2.6

• Modsoft Version ≥ V2.5

• ProWORX NxT Version V2.0

• ProWORX 32

• Platform: Transparent Ready

• Class Level: Class B10

Main Specifications

• Processor Type: x86-based (Intel, AMD)

• Clock Frequency: 50 MHz

• Communication Protocol: Ethernet

• Number of Ports:

• 1 I/O Bus

• 1 Ethernet Port

• Memory:

• 512 KB Flash

• 544 KB RAM

• Program Memory: 18 KB (LL984)

• Data Memory: 24 KB

• Word Length: 16-bit

• Discrete I/O Capacity: 8192 Inputs / 8192 Outputs

• Register I/O Capacity: 26048 Inputs / 26048 Outputs

• I/O Limit (Processor Capacity): 8192 bits max

• I/O Words per Drop:

• 128 I/O (Concept)

• 80 I/O (ProWORX)

• Instruction Execution Time: 1 ms per 1K instructions

• Supply Voltage: 5.0 V DC ±5%

• Power Supply Source: From Momentum I/O Base

• Material: Lexan

• Net Weight: 0.042 kg

Environmental Specifications

• Operating Temperature: 0 to 60 °C

• Storage Temperature: -40 to 85 °C

• Relative Humidity: 5% to 96% (non-condensing)

• Maximum Operating Altitude: 2000 m

• Shock Resistance: ≤ 15 g (11 ms half sine wave acceleration)

• Vibration Resistance:

• 0.75 mm displacement amplitude

• 1 g acceleration

• Protective Treatment: TC
